Automobile Grille Plastic Part Mold

I. Mold Application

The automotive grille plastic part mold is a specialized forming equipment in the automotive parts manufacturing field. Its core function is to process molten plastic raw materials into shape through a specific injection molding process to produce the front-end grille plastic parts of automobiles. As a key component of the automotive appearance system, the automotive grille not only protects the internal components of the engine compartment but also guides airflow to assist in heat dissipation and optimizes the aerodynamic characteristics of the vehicle body. Its shape and dimensional accuracy directly affect the coordination of the vehicle's appearance and the overall performance of the vehicle. This mold can precisely replicate the design configuration of the automotive grille, fully presenting the grille's grid structure, frame outline, installation tabs and other detailed features, achieving batch and standardized production of automotive grille plastic parts, and meeting the personalized and customized forming requirements of different vehicle models for grilles. It is a core supporting equipment for the industrialized manufacturing of automotive grilles.

II. Mold Materials

The material selection for automotive grille plastic part molds needs to comprehensively consider core elements such as mold service life, forming accuracy, processing feasibility, and cost control. The core materials are mainly divided into three categories: cavity/core materials, guiding and positioning materials, and auxiliary structural materials.

1. Cavity and core material: As the core functional area that directly contacts the mold and plastic raw materials, it needs to have high strength, high wear resistance, excellent thermal conductivity and corrosion resistance. Commonly used materials include pre-hardened plastic mold steels such as P20, 718H, and H13. Among them, P20 steel is suitable for medium-batch production of ordinary-precision grating molds and has good cutting and polishing performance; 718H steel has higher hardness and wear resistance and is suitable for large-batch production or complex-structured grating molds, effectively avoiding cavity wear and deformation during long-term molding processes; H13 steel is suitable for high-temperature-resistant molding scenarios and can meet the molding requirements of reinforced plastic raw materials such as polyamide (PA).

2. Guide and positioning materials: These are used to ensure the precise synchronization of the mold's opening and closing movements, preventing misalignment between the cavity and core that could lead to the scrapping of plastic parts. Commonly used materials include SUJ2 bearing steel. This material has extremely high hardness and dimensional stability. After quenching treatment, the wear resistance and fit accuracy of components such as guide pins and guide sleeves are significantly enhanced, ensuring the long-term stability and reliability of the mold's operation.

3. Auxiliary structural materials: This category includes auxiliary components such as ejector pins, tie bars, and sprue bushings. Commonly used materials are SKD61 hot work die steel and 45# steel. SKD61 hot work die steel is suitable for components like ejector pins that need to withstand repeated high-temperature impacts, offering excellent thermal fatigue resistance. After quenching and tempering treatment, 45# steel is suitable for non-core load-bearing components such as tie bars and fixed plates, achieving a balance between strength and cost-effectiveness.

III. Advantages of Molds

Compared with traditional processing methods, the use of automotive grille plastic part molds for production operations offers significant advantages in multiple dimensions. The core benefits are reflected in improved production efficiency, guaranteed product quality, optimized cost control, and enhanced adaptability to industrialization.

1. Enhance production efficiency and achieve batch production: The mold forming process adopts an integrated molding mode, where a single injection molding can complete the full molding of the car grille. Compared with the traditional process of disassembling and assembling, the production cycle is significantly shortened (the molding cycle of a single set of plastic parts is usually 30-60 seconds). At the same time, this mold can be adapted to an automated production line, and combined with a mechanical arm to achieve fully automated operations including feeding, molding, part removal, and trimming. A single mold can produce thousands of qualified plastic parts per day, which can efficiently meet the large-scale mass production needs of the automotive industry.

2. Ensure product accuracy, enhance appearance and assembly performance: During the mold design stage, the three-dimensional design data of the grille can be precisely replicated. The fit accuracy of the cavity and core can reach 0.005-0.01mm, effectively ensuring the dimensional accuracy, shape consistency and surface finish of the plastic part. After molding, the grille grid is regular, the frame is flat, and the installation snap dimensions are precise. This not only enhances the aesthetic appearance of the car but also ensures the precise assembly of the grille with the engine compartment, front bumper and other components, avoiding problems such as abnormal noise and airflow disorder caused by excessive assembly clearance.

3. Optimize cost control and enhance resource utilization efficiency: On the one hand, batch production can significantly spread out the mold allocation cost. Compared with manual processing or small-batch casting processes, the unit production cost of plastic parts can be reduced by 30% to 50%. On the other hand, the plastic raw material utilization rate in the mold forming process is over 95%, which can significantly reduce raw material waste. At the same time, the automated production mode reduces labor input, further optimizing the management of labor costs in the production process.

4. Adapt to personalized design and enhance product market competitiveness: With the continuous upgrading of personalized demands in the automotive market, the design styles of automotive grilles are becoming increasingly diversified. The automotive grille plastic mold can quickly complete the customization of the cavity structure according to the design requirements of different models, achieving rapid molding of differentiated grille shapes such as honeycomb, horizontal bar, and lattice, helping automakers quickly launch new products that meet market demands and effectively enhancing product market competitiveness.

IV. Process

The manufacturing and application of automotive grille plastic molds (plastic part molding) need to follow a series of rigorous process procedures. The core links are divided into two major modules: mold manufacturing process and plastic part molding process:

(1) Mold manufacturing process

1. Design stage: Based on the 3D design drawings of the automotive grille, combined with the characteristics of plastic raw materials (such as fluidity and shrinkage rate), the mold structure design work is carried out, covering the design of cavity and core shapes, gate position and form design, cooling system design, ejection system design, and other core contents. At the same time, CAE simulation analysis is used to optimize the mold structure and avoid potential quality problems such as shrinkage marks, warpage, and material shortage during the molding process in advance.

2. Material preparation: According to the design requirements, purchase the corresponding specification of mold steel materials, and complete the blanking processing through sawing machines, milling machines, and other equipment to obtain blank materials that meet the size requirements of each mold component.

3. Precision Machining: Precision machining equipment such as CNC milling machines, CNC machining centers, electrical discharge machines (EDM), and wire cutting machines are used to process the raw materials. Among them, CNC machining centers are used for rough and semi-fine processing of cavities and cores to ensure basic molding accuracy; electrical discharge machines are used to process complex curved surfaces and narrow slots inside cavities that are difficult to achieve through mechanical processing; wire cutting machines are used to process high-precision components such as guide columns and ejector pins.

4. Polishing and heat treatment: The surfaces of the cavity and core are polished to ensure that the surface roughness meets the requirements (typically Ra ≤ 0.02 μm), thereby enhancing the surface quality of the plastic part; the core components of the mold (such as the cavity, core, and guide pins) undergo heat treatment processes such as quenching and tempering to increase the hardness and wear resistance of the components.

5. Assembly and Debugging: Assemble the processed components (cavities, cores, guiding systems, ejection systems, cooling systems, etc.) and then install the mold on the injection molding machine to conduct trial molding operations. Produce sample parts through trial molding and inspect the sample parts for their dimensional accuracy, surface quality, assembly performance, and other indicators. Adjust and optimize the mold for any existing issues until the sample parts meet the quality standards.

(II) Plastic Part Molding Process

1. Raw material preparation: The selected plastic raw materials (such as polypropylene PP, acrylonitrile-butadiene-styrene copolymer ABS, polyamide PA, etc.) are dried to remove moisture from the raw materials and prevent bubble defects in the molded parts after molding.

2. Injection molding: After drying, the plastic raw materials are added to the injection molding machine's barrel. The raw materials are melted into a flowable state by heating in the barrel. Then, the injection molding machine's screw injects the molten plastic into the mold cavity at high pressure and high speed.

3. Pressure holding and cooling: After the plastic is injected into the cavity, the set pressure is maintained for pressure holding to compensate for the shrinkage of the plastic in the cavity. At the same time, the cavity is cooled through the mold cooling system to gradually solidify and form the molten plastic.

4. Mold opening and part ejection: Once the plastic part is completely solidified, the mold cavity and core are separated by the mold drive, and the plastic part is ejected from the cavity by the ejection system. The plastic part is then picked up and placed by a mechanical arm or manually.

5. Post-processing: The extracted plastic parts are trimmed (removing the gate, flash, and other excess materials), and quality control measures such as dimensional inspection and appearance check are carried out. Qualified plastic parts proceed to the subsequent assembly process.

V. Conclusion

As a core equipment for the industrialized manufacturing of automotive parts, the design rationality, material selection science, and processing accuracy of automotive grille plastic part molds directly determine the product quality, production efficiency, and cost control level of automotive grilles. With the automotive industry's continuous evolution towards lightweight, personalization, and intelligence, plastic grilles, featuring lightweight, flexible styling, and controllable costs, are increasingly widely used in automotive manufacturing. This places higher demands on automotive grille plastic part molds, such as higher molding accuracy, shorter mold development cycles, and stronger adaptability to complex structures. In the future, with the continuous upgrading of precision processing technology, CAE simulation technology, and automation technology, automotive grille plastic part molds will develop towards intelligence, efficiency, and greenness. This will not only further enhance the production quality and efficiency of automotive grilles but also assist the automotive industry in achieving efficient product iteration and performance improvement, providing a solid support for the high-quality development of the automotive manufacturing industry.
