Optimal Molding Process Parameters For SMC (Sheet Molding Compound)

The core of SMC (Sheet Molding Compound) molding process lies in matching the curing characteristics of the resin, the fiber impregnation state, and the structural requirements of the product. The optimal process parameters are not fixed values. They need to be determined comprehensively by considering the raw material properties, the thickness of the product, the complexity of the structure, and the quality requirements. The core focuses on four key parameters: temperature, pressure, time, and the timing of pressure application. Through a closed-loop process of basic calibration, experimental optimization, and verification iteration, these parameters are determined precisely. This can effectively avoid defects such as material shortage, bubbles, delamination, deformation, and poor curing, ensuring the mechanical properties and appearance consistency of the product.



I. Initial calibration of basic parameters: Determine the reference range of the parameters

Before formally optimizing the parameters, it is necessary to first conduct raw material testing and process condition prediction to determine the safe benchmark range for each parameter. This is to avoid theblindnessness of the experiments and is the prerequisite for determining the optimal parameters



Detection of raw material curing characteristics (the main basis)

The SMC raw materials were tested using the DSC differential scanning calorimeter to obtain the key curing parameters: gel temperature, curing exothermic peak temperature, complete curing temperature, and curing reaction rate. The process temperature needs to be set in accordance with the curing characteristics. The general principle is: the molding temperature is slightly lower than the curing exothermic peak temperature to avoid rapid resin curing that leads to insufficient flow and internal gas accumulation; for resin systems with fast curing rates, the low-temperature range is selected, and for those with slow curing rates, the high-temperature range is selected. The conventional temperature reference range is 135–170℃.



2. Four core parameter benchmark ranges and setting principles

Based on industry standard practices and actual production operations, determine the basic ranges for each parameter, and then make minor adjustments to the benchmarks according to the characteristics of the products.

molding temperature：The conventional optimal temperature range is 140–160℃. The temperature difference between the upper and lower molds should be strictly controlled within 5℃, and the temperature control accuracy should be ±2℃. For thin-walled products (thickness ≤ 3mm), the temperature range is 140–150℃ to prevent over-aging of the outer layer and incomplete curing of the inner layer; for thick-walled products (thickness ≥ 10mm), the temperature range is 150–160℃ to enhance the uniformity of internal curing and eliminate the problem of uneven curing caused by the temperature difference between the inside and outside.



Molded pressure：The normal range is 5-15 MPa, which is adjusted based on the projected area of the product and the complexity of its structure. For simple flat products, the pressure is set at 5-8 MPa. For products with reinforcing ribs, grooves, or complex curved surfaces, the pressure is set at 10-15 MPa. The tonnage of the press can be converted according to the projected area of the product, which is 30-80 kg/cm². The pressure must be sufficient to ensure that the material flows freely, fills the mold, and is compressed and vented properly. Insufficient pressure may cause bubbles and voids, while excessive pressure may result in overflow, fiber breakage, and excessive flyaway edges of the product.



Molding insulation time：Following the "thickness matching principle", the basic formula is: Insulation time = Product thickness × 0.8 - 1.2 minutes/mm. For thin-walled products, use a lower value, and for thick-walled products, use a higher value to ensure complete cross-linking and curing of the resin; too short a time results in incomplete curing, and the product's strength and weather resistance do not meet the standards; too long a time may cause resin aging, increased brittleness, and a decrease in production efficiency.



The timing of pressurization：The optimal timing is when the resin is about to gel but before it undergoes intense curing and heat release. It can be determined in three ways: by measuring the gel temperature critical point using DSC, by observing the material drawing state, and by analyzing the release pattern of the curing gas. Adding pressure too early will cause material overflow and fiber displacement; adding pressure too late will result in loss of material fluidity, leading to defects such as material shortage and fusion mark



3. Pre-event condition prediction

Based on the structure of the product, the status of the mold, and the production environment, the benchmark is adjusted: for SMC with a high glass fiber content, the pressure should be appropriately increased and the flow and holding pressure time should be prolonged; for precision appearance parts, the temperature difference and gradient temperature control should be reduced; when the mold is worn or the exhaust is poor, the pressure and the timing of pressure application should be slightly adjusted, and auxiliary exhaust measures should be taken.



II. Optimization of Scientific Experiments: Precisely Identifying the Optimal Parameter Combination

The benchmark range is merely a reference. It is necessary to conduct standardized experimental designs to quantify the impact of each parameter on the quality of the product, and select the optimal parameter combination that suits the product, thereby avoiding the errors caused by a single empirical judgment.



1. Preferred experimental methods (efficient, precise, low-cost)

Orthogonal experiment method: A commonly used core method in the industry. With temperature, pressure and time as the three major test factors, each factor is set at 3-4 gradient levels. The evaluation indicators are product impact strength, bending strength, appearance qualification rate and curing degree. Through range analysis and variance analysis, the influence weights of each parameter are clarified, and the optimal parameter combination is quickly screened out. With the least number of experiments, multi-factor optimization can be completed.

Response Surface Methodology (RSM): Suitable for high-precision products, it can establish a mathematical prediction model between parameters and product performance, precisely fitting the interaction effects of temperature, pressure, and time, and locking in the global optimal parameter combination to solve the problem of local optimality in orthogonal experiments.

Takatah Experimental Method: Focuses on optimizing parameter stability, can identify highly robust process parameters, reduce the impact of raw material fluctuations and equipment errors on product quality, and is suitable for large-scale batch production.



2. Unified evaluation index (the core criterion for determining the best option)

The optimal parameters must simultaneously meet the requirements in three aspects: appearance, performance, and production efficiency. None of them can be omitted.

Appearance: No bubbles, voids, layering, cracks, burrs, weld marks, and the surface finish meets the standard.

Performance: Solidification degree ≥ 95%, mechanical properties (tensile, bending, impact strength) are stable and meet standards, without warping deformation or dimensional deviation;

Efficiency: No excessive time consumption, no waste of overflows, suitable for batch production rhythm.



III. Defect Reverse Calibration: Iterative Optimization of Parameter Accuracy

In response to the typical defects that emerged during the trial production, adjusting the process parameters in reverse to achieve precise parameter implementation is a crucial iterative step for finalizing the optimal parameters:



Bubbles, pores, and layering: appropriately increase the molding pressure, optimize the timing of pressure application (apply slight pressure for venting in advance), reduce the temperature difference between the mold, and extend the short-term holding pressure time;



Incomplete curing, product being too soft: Slightly increase the molding temperature or extend the holding time to prevent the temperature from being too low and the reaction from not being complete.



The products crack and turn yellow and aged: Reduce the molding temperature and shorten the insulation time to prevent the resin from undergoing excessive thermal curing and aging.



Insufficient materials, obvious welding marks: Adjust the temperature rise curve, delay the pressurization time, to ensure that the materials flow and fill the mold fully.



Warpage deformation: Optimizes the uniformity of the temperature between the upper and lower molds, reduces pressure gradient deviations, and matches the different insulation times for thick and thin areas.





IV. Batch Verification and Parameter Calibration

After the parameter combinations have been selected through experiments and calibrated for defects, they need to undergo small-scale trial production (50-100 pieces) for verification: continuous inspection of the appearance, size, mechanical properties, and curing degree of the products is conducted to confirm the stability and consistency of the parameters, and to ensure there are no batch defects or performance fluctuations. Once this is achieved, the parameters are fixed as the optimal standardized process parameters for the product. At the same time, a parameter ledger is formed. In the future, when adjusting the raw material batches or the structure of the products, the optimal benchmark can be used for rapid iterative adaptation.





V. Core Summary: Logic for Determining Optimal Parameters

The optimal process parameters for SMC molding are not fixed values but the best combination that suits the characteristics of the raw materials, the structure of the product, and the quality requirements. The core process is as follows: the temperature benchmark is determined through DSC testing of the raw materials; the pressure and time benchmarks for the product thickness structure are determined; orthogonal or response surface experiments are conducted for optimization; defect reverse calibration is performed; and batch stability verification is carried out. Ultimately, this achieves the optimal product quality, the highest production efficiency, and the lowest defect rate.
